Introduction

This is the bitemporal installment of the Crux "choose your own adventure" tutorial series.

We shall assume you have a Crux standalone node set up locally and are now comfortable with put operations and basic datalog queries. If this is not the case, you can find all you need to know on Earth, Pluto and Mercury. Click on a destination above to take you there.

Arrival on Neptune

You enter the Neptunian atmosphere and your communications panel lights up.

It is our honor to welcome you to the planet Neptune.

If you are visiting for business reasons, please present your manifest.

Otherwise, have your visa ready for inspection.

— Poseidon Republic of Wealth

The government is asking to see your flight manifest.

Choose your path:

You have your manifest

You do not have your manifest

You have permission to land

You do not have permission to land. You must return to Mercury and fill in your manifest.

Space Port

On your way down to the landing site you take the time to read the Crux manual.

One or more documents can be inserted into Crux via a put transaction at a specific valid-time. The valid-time can be any time (past, future or present).

If no valid-time is provided, Crux will default to the transaction time, i.e. the present. Each document survives until it is deleted or a new version of it is added.

— Crux manual
Read More

Assignment

Upon landing on the ice giant, your communications panel lights up indicating that the job ticket is available.

Ticket

Task	`Back fill insurance documents`
Company	`Coast Insurance`
Contact	`Lyndon Mercia-York`
Submitted	`2115-02-22T13:38:20`
Additional information	`We have lost a lot of our records in a flood. I think it is prudent to start storing our data digitally. It is important to track policy holders' level of cover at the time of the incident. We have read a lot about the conveniences of Crux’s bitemporality in this situation. We need you to help us get up and running. Please send someone quickly though - the waters are rising.`
Attachments	—

Outside your ship you are met by a panicked looking Lyndon.

Thank goodness you’re here.

We need you to show us how to put our customers information into Crux in order of time. Working with insurance claims, we should be able to easily look back in time at what type of coverage the customer had at the time of the incident.

Are you able to help us?

— Lyndon Mercia-York
Coast Insurance

Choose your path

"Yes I’ll give it a go."

"I’m not sure how to even begin."

Lyndon gives you some data for a client that you can use as an example. Coast Insurance need to know what kind of cover each customer has and if it was valid at a given time.

You show them how to ingest a document using a valid-time so that the information is backdated to when the customer took the cover out.

(crux/submit-tx
 node
 [[:crux.tx/put
   {:crux.db/id :consumer/RJ29sUU
    :consumer-id :RJ29sUU
    :first-name "Jay"
    :last-name "Rose"
    :cover? true
    :cover-type :Full}
   #inst "2114-12-03"]])
;;=> #:crux.tx{:tx-id 0, :tx-time #inst "2020-06-18T14:38:29.240-00:00"}

The company needs to know the history of insurance for each cover. You show them how to use the bitemporality of Crux to do this.

(crux/submit-tx
 node
 [[:crux.tx/put (1)
   {:crux.db/id :consumer/RJ29sUU
    :consumer-id :RJ29sUU
    :first-name "Jay"
    :last-name "Rose"
    :cover? true
    :cover-type :Full}
   #inst "2113-12-03" ;; Valid time start
   #inst "2114-12-03"] ;; Valid time end

  [:crux.tx/put (2)
   {:crux.db/id :consumer/RJ29sUU
    :consumer-id :RJ29sUU
    :first-name "Jay"
    :last-name "Rose"
    :cover? true
    :cover-type :Full}
   #inst "2112-12-03"
   #inst "2113-12-03"]

  [:crux.tx/put (3)
   {:crux.db/id :consumer/RJ29sUU
    :consumer-id :RJ29sUU
    :first-name "Jay"
    :last-name "Rose"
    :cover? false}
   #inst "2112-06-03"
   #inst "2112-12-02"]

  [:crux.tx/put (4)
   {:crux.db/id :consumer/RJ29sUU
    :consumer-id :RJ29sUU
    :first-name "Jay"
    :last-name "Rose"
    :cover? true
    :cover-type :Promotional}
   #inst "2111-06-03"
   #inst "2112-06-03"]])
;;=> #:crux.tx{:tx-id 1, :tx-time #inst "2020-06-18T14:39:11.189-00:00"}

This is the insurance that the customer had last year. Along with the start valid-time you use an end valid-time so as not to affect the most recent version of the document.
This is the previous insurance plan. Again, you use a start and end valid-time.
There was a period when the customer was not covered,
and before that the customer was on a promotional plan.

Queries through time

You now show them a few queries. You know that you can query Crux as of a given valid-time. This shows the state of Crux at that time.

First you chose a date that the customer had full cover:

(crux/q (crux/db node #inst "2115-07-03")
        '{:find [cover type]
          :where [[e :consumer-id :RJ29sUU]
                  [e :cover? cover]
                  [e :cover-type type]]})
;;=> #{[true :Full]}

Next you show them a query for a the customer in a time when they had a different type of cover:

(crux/q (crux/db node #inst "2111-07-03")
        '{:find [cover type]
          :where [[e :consumer-id :RJ29sUU]
                  [e :cover? cover]
                  [e :cover-type type]]})
;;=> #{[true :Promotional]}

And finally you show them a time when the customer had no cover at all.

(crux/q (crux/db node #inst "2112-07-03")
        '{:find [cover type]
          :where [[e :consumer-id :RJ29sUU]
                  [e :cover? cover]
                  [e :cover-type type]]})
;;=> #{}

Confident in their ability to put the remainder of their records into Crux, Lyndon thanks you.

I can’t believe we’ve not digitized sooner. There was a huge push to start using more paper as the Neptune tree population was getting out of control from the accelerated terraforming, but since all these floods I’m not sure paper was the right choice.

— Lyndon Mercia-York
Coast Insurance

You say goodbye to Lyndon and head back to the space port.

Space Port

Back at your spaceship you check your communications panel. There is a new assignment waiting for you.

We have assigned you a quick task on Saturn helping a small company who are having some problems keeping their records in order.

This shouldn’t take long, but don’t forget they will still need to see your manifest.

— Helios Banking Inc.

Update Manifest

You add the new badge to your manifest

(crux/submit-tx
 node [[:crux.tx/put
        (assoc manifest
               :badges ["SETUP" "PUT" "DATALOG-QUERIES" "BITEMP"])]])
;;=> #:crux.tx{:tx-id 2, :tx-time #inst "2020-06-18T14:46:47.606-00:00"}

Enter countdown for lift off, destination: Saturn. See you soon.

Click on Saturn to take you to your next assignment.
