Configuration: Make it obvious!

Avoid misleading application configuration schemes by being explicit

by Malcolm Sparks

Published 2016-05-03

Most applications need to leave some choices in the hands of their users. For example, you might be launching some network service on a fixed port number, but unless you've actually reserved that port with the Internet powers-that-be, it's possible some other application is using that port and it has to be possible for the user to change it. You might also need the user to provide settings that you cannot possibly know when you are developing the application, such as the connection string to a database.

Environment variables

One approach is to declare your configuration in environment variables.

PORT=8000
DATABASE=datomic:dev://localhost:4334/my-db

That is OK when there are only a few straight-forward settings that can be modified, but as the application's complexity increases it is likely that you will want many such settings, and often you want to specify lists and nested groupings.

There are schemes to name environment variables in a certain way to achieve greater complexity but ask for constructions like this (which for me are somewhat awkward and doesn't feel like the Unix I know and love)

KNOWN-USERS.0.NAME=Alice
KNOWN-USERS.1.NAME=Bob

A better approach is to store your application's configuration in plain-text in a file that the user can edit. EDN makes a great choice because you can exploit Clojure's great literal syntax of nested data structures:

{:port 8000
 :database "datomic:dev://localhost:4334/my-db"
 :known-users [{:name "Alice"} {:name "Bob"}]}

Multiple environments

"Some things change, some stay the same."

– Hymn to Her, The Pretenders

Your application may need to run in different environments for different purposes. A common case is that you have one environment for your users and another similar environment for you to test against. Very often, the application's configuration differs on a per-environment basis.

There are a number of ways of dealing with this situation.

Separate configuration files

You may have heard the DRY principle (Don't Repeat Yourself) which warns us against duplicating information. When information is duplicated it's easy for discrepancies to creep in. If you need to change a value, you need to find all the places where that value is repeated, and this is highly error prone. It also reduces our ability to reason about a system.

If we want to be able to reason about a system we first need to be able to trust the data we have in front of us.

If we have a separate configuration file for each environment, we can fall into the trap of rampant duplication, which destroys that trust.

We must be able to trust that accuracy of configuration data. Duplication corrodes that trust.

Configuration layering

Configuration layering is where you stratify configuration over a number of layers. The bottom layer provides the defaults (perhaps in a configuration file). The layer up provides the environment's overrides.

For example, the override file for a test environment may wish to keep the port setting the same as the default, but specify a new setting for the database connection string.

{:database "datomic:dev://localhost:4334/my-test-db"}

Why not have more layers? You could build a configuration scheme whereby configuration is built up from a number of sources, some perhaps a network hop away. 'Zero-configuration' schemes make good use of this pattern.

However, there are some significant trade-offs with flexible configuration schemes. The worst of these, in my opinion, is that configuration becomes implicit and non-obvious, leading to lengthy and sometimes tortuous debugging sessions:

Imagine you are brought in to diagnose a critical outage with our application. You might find the original configuration file and assume the database being used was "datomic:dev://localhost:4334/my-db". You access that database and rummage around trying to find the problem, only to discover (hours later perhaps) that the actual database in use was "datomic:dev://localhost:4334/my-prod-db2". After much head-scratching, you realise there was a clever hidden configuration overridden built into the application code that pulled in an override file. The criticality of these situations tends to be amplified by the fact that configuration issues usually happen in production, simply because they are often the only untested part of a production system. Configuration systems are unforgiving when it comes to human error.

Again, we must be able to trust that accuracy of configuration data. Layering has the potential to mislead us. That's not to say layering is a bad choice and we very much like the design of Clojure libraries such as environ and nomad.

The Aero approach

Aero is a configuration library from JUXT which encourages explicit and obvious configuration. In Aero, we would implement the requirements already described by following configuration file:

{:port 8000
 :database #profile {:prod "datomic:dev://localhost:4334/my-prod-db2"
                     :test "datomic:dev://localhost:4334/my-test-db"
                     :default "datomic:dev://localhost:4334/my-db"}
 :known-users [{:name "Alice"} {:name "Bob"}]}

In this example, it should be quite clear what the various values for the database are, for each environment. Aero asks the application to provide a single value called the profile and this is used to switch between environment-dependent values.

In most end-user situations, configuration files can and should be put in version control (except for sensitive information such as passwords, which we'll come to soon). It is understandable to want to keep the application code separate from its operational deployment details, but in most cases the benefits outweigh the costs. The ability to reason about a system, in all its glorious detail, is a prize worth striving for.

Secrets

There are obviously some settings that contain sensitive data such as passwords and private cryptographic keys that you must restrict access to.

Some think this is a good reason to bring back environment variables, since they can be configured externally and exported into the application from outside.

In my view, environment variables are a very poor choice for sensitive information. It's very easy for environment variables to viewed. A simple 'ps -ef' will reveal the environment of a process. You can also view them in the '/proc' files-system.

Also, environment variables can be helpful in deployment situations and it is often useful to make the current environment accessible via a web-page or dump them to a debug log. If you environment contains sensitive details then this idea becomes dangerous and would involve the removal of the sensitive variables prior to output.

Rather, it is better to store your secrets in a separate file, which can only be read by the application account user.

Loading secrets with Aero

Aero comes with some useful EDN tag literals that you can use to read a private configuration file.

The first is #include, which lets us import some extra configuration from another file.

{:extra #include "my-extra-config.edn"}

This assumes the current working directory contains the my-extra-config.edn file. It would be better to avoid that assumption by giving an absolute path.

If our file is in the HOME directory of the application user we can access this with #env.

{:home-dir #env HOME}

Now we can construct the absolute filename by joining the HOME directory to the file path using Aero's #join tag literal, which is followed by a vector of components to join.

{:file #join [#env HOME "my-extra-config.edn"]}

This works because tag literals compose.

Putting it all together, we may end up with something like this:

{:website
 {:port 8000
  :database #profile
  {:prod "datomic:dev://localhost:4334/my-prod-db2"
   :test "datomic:dev://localhost:4334/my-test-db"
   :default "datomic:dev://localhost:4334/my-db"}
  :known-users [{:name "Alice"}
                {:name "Bob"}]
  :oauth2 ^:ref [:secrets :oauth2]}

 :secrets #profile
 {:dev
  {:stripe {:key "sk_test_123"}
   :mailgun {:api-key "key-123"}
   :oauth2
   {:google
    {:client-id "cs-123"
     :client-secret "wbefes"}}}
  :prod #include #join [#env HOME "/.secrets.edn"]}}

Notice that this is still a valid EDN file. Aero is (mostly) defining a set of tag literals. In most cases, we are using the #profile tag literal. In the last line, where we bring in another EDN file we compose the #include, #join and #env tag literals together.

Notice how EDN tag literals easily compose to give a degree of flexibility without resorting to adding language features into the configuration syntax (or horror-of-horrors, making the configuration itself Turing complete).

Also notice how we use ^:ref metadata to reference the otherwise isolated part of the configuration that deals with secrets.

The result is a configuration file that is consistent, complete and explicit. When combined with the process environment we have all the information we need to reason about a system (except for the secrets, which are hidden from us) .

Integrating Aero with Stuart Sierra component

Stuart Sierra's component library asks us to create a system as a map of components. We then must ask the component library to start the system, where each component is given their started dependencies and started. But between these steps we can configure our system such that each component is configured with its corresponding section in the Aero configuration file.

The only constraint is that we align our system map keys with our configuration keys, but that is a reasonable design and consistent choice.

Each component can then declare configurable settings in its record definition header and these are available in both the start and stop functions.

(defrecord Website [port database known-users oauth2]
  component/Lifecycle
  (start [component] ...)
  (stop [component] ...))

Then we create our system out of components, specifying defaults if necessary (despite what I have said about the pitfalls of configuration layering, there are times where you certainly need to specify a hard-coded default).

(defn new-system {:website (map->Website {:known-users []})})

Finally we configure our system with a function that merges the system map with the configuration map.

(defn configure [system profile]
  (merge-with merge
     system
     (aero.core/read-config "config.edn" {:profile profile})))

Aero extensibility

Finally, it's worth mentioning that Aero is extensible.

Garner Vickers has contributed a welcome improvement to Aero to allow tag literals to be defined as defmethods.

For example, let's say you want to add a buddy hasher to hash a string to a byte array, doing this in the config directly rather than having to write code. Now you can write something like this:

{:session-secret #buddy.hash/sha256 "my secret passphrase"}

adding the following defmethod:

(require '[buddy.core.hash :as hash])

(defmethod aero.core/reader 'buddy.hash/sha256
  [opts tag value]
  (hash/sha256 value))

Conclusion

Configuration schemes that use implicit and allow overrides can lead to situations where it is hard to reason about a system. It's better, whenever possible, to use explicit schemes that make it obvious what configuration values are set to.

JUXT's Aero library provides a balanced trade-off between then needs of flexibility, security and accuracy and it suitable for a majority of small to mid-sized Clojure systems, and can provide a flexible bootstrapping scheme for larger ones.
